Demo AEG7MH-WK Ibanez Acoustic Guitar

Ibanez AEG7MH-WK – Acoustic Guitar w/ Pickup (Weathered Black Open Pore) Demo Unit!

The AEG7MH features a thinner grand concert-shaped body with a soft Venetian cutaway constructed of a laminated sapele top with binding on sapele sides and back with an open pore finish. The round soundhole has a black & white acrylic rosette. It has an okoume neck with a 25″ scale and, a 20-fret purpleheart fingerboard with small white dot position markers. Components include a plastic saddle in a purpleheart bridge, Ibanez Advantage bridge pins, a plastic nut, and chrome Ibanez die-cast tuning machines. Electronics consist of an Ibanez under-saddle pickup connected to an Ibanez AEQ-2T preamp with an onboard tuner powered by a 9V battery and ¼” stereo output.

Specifications

Body Shape: AEG body
Top: Sapele top
Back & Sides : Sapele back & Sapele sides
Neck : AEG, Okoume neck
Fretboard: Purpleheart fretboard
Bridge: Purpleheart Bridge
Inlay: White dot inlay
Soundhole Rosette: Black & White multi
Tuning Machine: Chrome Die-cast tuners
Number of Frets: 20
Bridge Pins: Ibanez Advantage™
Strings: Ibanez IACS6C
String Gauge : .012/.016/.024/.032/.042/.053
String Space: 11mm
Factory Tuning : 1E,2B,3G,4D,5A,6E
Pickup: Ibanez undersaddle
Preamp : Ibanez AEQ-2T preamp w/Onboard tuner
Output Jack: 1/4″ output
Battery: 9V x1

Neck Dimensions
Scale: 634mm/25″
Width: 43mm at NUT
Width: 55mm at 14F
Thickness: 20mm at 1F
Thickness: 21mm at 7F
Radius: 400mmR

Body Dimensions
Length: 19 3/8″
Width: 15″
Max Depth : 3 3/4″
