Description
- Specifications
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohms or greater
- Controls
-
Pedal switch
Mode switch
LEVEL knob
TONE knob
GAIN knob - Indicator
- CHECK indicator (Serves also as battery check indicator)
- Connectors
-
INPUT jack
OUTPUT jack
DC IN jack - Power Supply
-
Alkaline battery (9 V, 6LR61) or Carbon-zinc battery (9 V, 6F22)
AC adaptor (sold separately) - Current Draw
- 18 mA
- Accessories
-
Owner’s Manual
Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTE,” and “Information”)
Carbon-zinc battery (9 V, 6F22) - Option (sold separately)
- AC adaptor (PSA series)
- Size and Weight
- Width
-
73 mm
2-7/8 inches - Depth
-
129 mm
5-1/8 inches - Height
-
59 mm
2-3/8 inches - Weight
-
430 g
0 lbs. 16 oz.
