Loudspeaker Features:
- Transducers:
- 12″ ferrite magnet woofer (912G)
- JBL 2408H-2 1.5″ poly-annular diaphragm compression driver
- Amplification:
- Lightweight, efficient Class D amplification
- 2,000 watts peak/1,000 watts RMS
- Frequency Response: 50 Hz–20 kHz @4pi (-10 dB); 65 Hz–17 kHz @4pi (-3 dB)
- Max SPL: 132 dB
- Dispersion: 90° x 50°
- Crossover: 2,050 Hz
- DriveRack Technology:
- Includes Automatic Feedback Suppression (AFS), system limiter, and speaker delay
- Optimized presets for pairing full-range speakers with subwoofers
- G-Sensor: Automatic Position Detect optimizes tuning for main or monitor orientation
- Color LCD Screen: Access to comprehensive DSP suite
- Connectivity:
- 2 XLR balanced Combo jacks
- 1 3.5mm aux, 2 XLR-M loop-through, and 1 XLR-M mix-out
-
Loudspeaker features:
- Transducers:
- 12″ ferrite magnet woofer (912G)
- JBL 2408H-2 1.5″ poly-annular diaphragm compression driver
- Amplification:
- Lightweight, efficient Class D amplification
- 2,000 watts peak/1,000 watts RMS
- Frequency Response: 50 Hz–20 kHz @4pi (-10 dB); 65 Hz–17 kHz @4pi (-3 dB)
- Max SPL: 132 dB
- Dispersion: 90° x 50°
- Crossover: 2,050 Hz
- DriveRack Technology:
- Includes Automatic Feedback Suppression (AFS), system limiter, and speaker delay
- Optimized presets for pairing full-range speakers with subwoofers
- G-Sensor: Automatic Position Detect optimizes tuning for main or monitor orientation
- Color LCD Screen: Access to comprehensive DSP suite
- Connectivity:
- 2 XLR balanced Combo jacks
- 1 3.5mm aux, 2 XLR-M loop-through, and 1 XLR-M mix-out
- JBL Pro Connect App: Full system control of up to 10 speakers
- Cabinet: Polypropylene/talcum composite for durability and rigidity
- Mounting/Suspension: Dual 36mm pole socket, six M10 suspension points
- Weight:
- Net: 19.5 kg (43 lbs)
- Gross: 23.5 kg (51.8 lbs)
- Dimensions: 636 mm x 394 mm x 332 mm (25.04 in x 15.5 in x 13 in)
- Shipping Dimensions: 668 mm x 506 mm x 444 mm (26.3 in x 19.9 in x 17.5 in)
JBL Pro Connect App: Full system control of up to 10 speakers
- Transducers:
- Cabinet: Polypropylene/talcum composite for durability and rigidity
- Mounting/Suspension: Dual 36mm pole socket, six M10 suspension points
- Weight:
- Net: 19.5 kg (43 lbs)
- Gross: 23.5 kg (51.8 lbs)
- Dimensions: 636 mm x 394 mm x 332 mm (25.04 in x 15.5 in x 13 in)
- Shipping Dimensions: 668 mm x 506 mm x 444 mm (26.3 in x 19.9 in x 17.5 in)
