Wharfedale TYPHON-AXF8-BT
The TYPHON-AXF8-BT is an 8″ bi-amplified active loudspeaker, the next evolution of the acclaimed TYPHON range, now enhanced with FIR filtering and improved crossover design for even better sonic performance — now with integrated Bluetooth connectivity.
Delivering 720 W continuous and 1440 W peak power with a maximum SPL of 127 dB at 1 m, it features a custom Wharfedale Pro 8″ LF driver with a 2.5″ voice coil and a 1.75″ HF compression driver for precise, detailed sound. The updated DSP provides improved bass response, refined phase alignment and a smoother overall frequency balance.
Built into the same rugged polypropylene cabinet as the original Typhon-AX models, Typhon-AXF8-BT retains full IP54 certification, multiple rigging points and convenient carry handles. With its Class D bi-amplified design and advanced DSP architecture, it delivers next-level clarity, control and power for professional applications. Pair it with a T-SUB-AX sub for a perfectly matched low-frequency extension.
| Specification | Value |
|---|---|
| Active or Passive | Active |
| System Type | Full-Range |
| Configuration | 2-way |
| System Continuous Power | 720 W |
| System Peak Power | 1440 W |
| Max SPL @ 1m | 127 dB |
| Freq Response (+/-3 dB) | 65 Hz - 20 kHz |
| Freq Range (-10 dB) | 60 Hz - 20 kHz |
| Bluetooth | Yes |
| IP Certification | IP54 |
| Driver Brand | Wharfedale Pro |
| LF Driver Size | 8" |
| LF Voice Coil Size | 2.5" |
| LF Rated Impedance | 4 Ω |
| LF Power (RE:AES2-2012) | 200 W |
| HF Driver Type | Compression Driver |
| HF Voice Coil Size | 1.75" |
| HF Diaphragm Material | Titanium |
| HF Exit Size | 1" |
| HF Power (RE:AES2-2012) | 40 W |
| HF Rated Impedance | 8 Ω |
| Preset Library | No |
| Input Connector | 2 x 1/4" Jack / XLR Combo, 2 x RCA, BT |
| Waveguide Type | Hybrid Symmetry Horn |
| Enclosure Material | Polypropylene |
| Grille Material and Finish | Steel Black |
| Finish | Black Polypropylene |
| Handles | 4 |
| Deployment | Flying, Pole, Wall Mount, Ground |
| Pole Mount | 35 mm With Lock Screw |
| Brackets Included | No |
| Rigging | Yes |
| M8 | 9 |
| Nominal Coverage (H x V) | 100° x 80° |
| Sensitivity 2.83 V / 1 m | 96 dB |
| System Rated Impedance | n/a |
| Crossover Frequency | 2.3 kHz |
| Amplifier design | Class D |
| DSP Controls | Flat / Monitor / Bass / Punch (with FIR) |
| Preset list | Flat / Monitor / Bass / Punch (with FIR) |
| Active loudspeaker Input Impedance | 20 KΩ |
| Link Connector | pin XLR |
| Input sensitivity | 775 mV (0 dBu) |
| Max input level | 4 V |
| Line output | Pin XLR |
| Main Power | 100-120 V~/200-240 V~, 50/60 Hz |
| Power Supply | SMPS |
