Wharfedale WLA-210XP
Dual 10" line array element with EVO-FoldFrom R 1,574.58 per month
-
4× fortnightly payments of R4,723.75 with
-
12× monthly payments of R1,574.58 with
Delivery: Fast Shipping – Door to Door Standard Delivery
Collection: Free In Store Collection
Product ID: 15260691071142
Wharfedale WLA-210XP
- Dual 10″ passive
- 138 dB Max SPL @ 1 meter
- 15 mm / 18 mm Birch plywood construction
- 100° x 10° dispersion
- 800 W LF + 90 W HF Continuous
- 1600 W LF + 180 W HF Programme
- 3200 W LF + 360 W HF Peak
2 x High powered 10” LF drivers; 3.2” neodymium HF driver with EVO-Fold waveguide; 132dB Max SPL; 1600W peak power - Passive Boxes
Using the advanced hardware technologies deployed in the WLA-210A, the new WLA-210XP is the passive variant.
WLA-210XP features custom phase plugs and the extra-ordinary Wharfedale Pro EVO-Fold waveguide. Combined, these lead to a huge reduction in the usual phase issues that traditional 2-way line arrays have due to them having the drive units physically some distance apart in the array.
The matching dual 15″ passive subwoofer (pictured), WLA-210XSUB, is the perfect partner for WLA-210XP. Meanwhile, the optional WLA-210X Common Fly Frame completes the system and allows for versatile system configurations of either subwoofer or array elements or both..
The WLA-210XP system is supported with downloadable FIR presets for DP-F / N series amplifiers. FIR presets are also available for the SC-48 FIR Loudspeaker Management System for use with other amplifiers such as XR series or CPD series. For detailed system design WLA-210XP is also supported with downloadable .gll files for Ease Focus.
WLA-210XP has been designed and engineered in the UK and is targetted at the touring and fixed install sectors
| Specification | Value |
|---|---|
| Active or Passive | Passive |
| System Type | Array Element |
| Configuration | 2-way |
| System Continuous Power | LF: 800 W / HF: 90 W |
| System Programme Power | LF: 1600 / HF: 180 W |
| System Peak Power | LF: 3200 / HF: 360 W |
| Max SPL @ 1m | 138 dB |
| Freq Range (-10 dB) | 50 Hz - 20 KHz |
| Freq Response (+/-3 dB) | 58 Hz - 20 KHz |
| Bi-amp Mode Switch | Yes |
| Bluetooth | No |
| IP Certification | None |
| Driver Brand | Wharfedale Pro |
| LF Driver Size | 2 x 10" |
| LF Magnet Material | Ferrite |
| LF Frame Material | Aluminium |
| LF Voice Coil Size | 2.5” |
| LF Rated Impedance | 2 x 16 Ω (Parallel) |
| LF Power (RE:AES2-2012) | 2 x 400 W |
| HF Driver Type | Compression Driver |
| HF Voice Coil Size | 3” |
| HF Diaphragm Material | Titanium |
| HF Exit Size | 1.4″ |
| HF Power (RE:AES2-2012) | 90 W |
| HF Rated Impedance | 8 Ω |
| HF Nominal Coverage (H x V) | 100° x 10° |
| Preset Library | Yes |
| Input Connector | 2 x 4 Pole Speaker Connector |
| Waveguide Type | EVO-Fold |
| Enclosure Material | Birch Plywood |
| Grille Material and Finish | Steel |
| Finish | Black Tough-Tone |
| Handles | Yes |
| Deployment | Flying, Ground |
| Pole Mount | None |
| Brackets Included | Yes |
| Rigging | Yes |
| Integral Rigging | 3 Points |
| Sensitivity 2.83v / 1m | 102 dB |
| System Rated Impedance | 8 Ω |
| Crossover Frequency | 1.5 KHz |
| Recommended HPF = BW 18 dB/OCT. | 50 Hz |
| Included Accessory | User Manual |
| Unpacked - Front Height (mm) | 314 |
| Unpacked - Rear Height (mm) | 240.2 |
| Unpacked - Width Front (mm) | 760 |
| Unpacked - Width Rear (mm) | 760 |
| Unpacked - Depth (mm) | 504 |
| Packed - Height (mm) | 404 |
| Packed - Width Front (mm) | 855 |
| Packed - Width Rear (mm) | 855 |
| Packed - Depth (mm) | 594 |
| Weight - Nett (kg) | 38.8 |
| Weight - Gross (kg) | 41.3 |
Whats in the Box:
1 x Wharfedale WLA-210XP
